Specifications
| Rotor speed | 0.3/0.5/0.6/1/1.5/2/2.5/3/4/5/6/10/12/20/30/50/60/100/200rpm |
| Measurement range | In 76 ranges 3 to 2,000,000 mPa.s/3 to 2,000,000 cP; 19 to 4 spindles |
| Measurement range of temperature sensor | -15~+180 ℃ / +5~+356 ° F |
| temperature Accuracy | ±0.1 ℃ |
| Accuracy | +/- 1% of full scale (FS) |
| Repeatability | ±0.2％F.S |
| Power supply Voltage | 100~240 V / 50~60 Hz |
| Current consumption | 0.2 A |
| Operating temperature | +10~+40℃ / +50~104°F |
| Relative Humidity | <80％ |
| Maximum height | Altitude 2000 meters/6,561 feet |
| size | 330 × 300 × 430mm/13.0 × 11.8 × 17.0 inches |
| Weight | 10.0 kg/22.1 lb |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36299/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
