Specifications
| Power supply Voltage | AC220V±10% 2A 50Hz |
| Error of indication | ±1% |
| Indication variability | ＜1% |
| Force resolution | 0.1N |
| Force range | 1~3000N |
| Up and down platen parallelism | ≤0.05mm |
| Working Travel | 1~60mm |
| Pressurization speed | 12.5±1.5mm/min |
| Upper and lower pressure plate size | Φ120mm |
| Human Machine Interface | Chinese and English menus; touch screen display, 5.5-inch touch screen |
| printout | modular integrated thermal printer |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | 390*240*540mm |
| Weight | About 45kg |
Packing list
Host X1, power cord X1, manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36354/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
