Specifications
| Measurement structure | D/8, SCI + SCE (diffuse illumination/8 ° direction reception, including specular reflection and removal of specular reflection) |
| Repeatability of chromatic value | Standard deviation dE * ab ≤ 0.025; Average: dE * ab ≤ 0.025; MAX Maximum: dE * ab ≤ 0.04 |
| Spectroscopic reflectance Repeatability | Standard deviation less than 0.08% |
| Inter-instrument Agreement | ΔE*ab<0.25 |
| Measurement/Lighting Aperture | MAV:Φ8mm/Φ11mm；SAV:Φ4mm/Φ6mm；MINI:1*3mm |
| Measurement index | Light spectrum reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, color difference, whiteness, yellowness, Blackness, colour fastness, discoloration fastness, Tint, color density CMYK (A, T, E, M), isochromatic index Milm, Munsell, hiding power, force |
| Available Light Sources | A, B, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, U35, DLF, NBF, TL83, TL84, ID50, ID65, LED-B1, etc |
| Lighting source | LED (Full Band Balanced LED Light source) + UV |
| Camera viewfinder positioning | Yes. |
| Calibration method | Automatic calibration |
| Software support | Android, IOS, WeChat Mini Program, Windows |
| Accuracy | Guaranteed Level 1 Measurement Qualification |
| Viewing Angle | CIE 2°/10° |
| Integrating sphere size | Φ40mm |
| Display Accuracy | 0.01 |
| spectroscopic mode | grating |
| Sensor | Dual Array Sensors |
| wavelength interval | 10nm |
| Wavelength range | 400-700nm |
| Reflectance Measurement Range | 0~200% |
| Reflectance resolution | 0.01% |
| Measurement time | Less than 2s |
| Interface | USB, Bluetooth |
| Display | IPS full color screen 3.5 inches |
| Battery life | Single charge can be continuously measured 8000 times, 3.7V/3000mAh |
| Light source lifetime | 10 years 1 million times |
| Operating language | Simplified Chinese, English |
| store data | APP Mass storage |
| meet the standard | Compliant with standards CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36452/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
