Specifications
| Power | 220V 50/60HZ |
| Stirring amount ml | 500 |
| Allowable emulsification ml | 1000-2000 |
| Vacuum can be achieved | -0.097---0.02mpa |
| 处理Viscosity | 10000mpas |
| Stirring speed range | 0-230rpm |
| Impeller configuration | Anchor Ribbon Scrape Stirring Paste |
| Scraper material | silicone rubber |
| Homogeneous motor power | 500W |
| Homogeneous velocity range | 10000-30000rpm |
| Homogeneous working head configuration | 25DG |
| Reaction kettle cover opening | Homogenizer port + hopper port + temperature measurement port + vacuum port + 3 spare ports |
| Lifting bracket travel | 210mm |
| Main contact material with material | SS316L, Borosilicate Glass, FKM10 |
| Outer diameter of vacuum port | 10mm |
| Glass kettle jacket inlet and outlet outer diameter | 12mm |
| Allowable environment temperature ℃ | 5-40 |
| Allowable relative temperature ℃ | 80 |
| Standard Weight kg | 38 |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36495/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
