Specifications
| kettle Capacity | 5L |
| Number of kettles | 5 |
| Cover diameter | 180mm |
| Cover length | 400mm |
| Stirring power | 60W |
| speed | 50-600rpm |
| Ultrasonic frequency | 20-25KHz |
| Ultrasonic maximum power | 1800W |
| Ultrasonic pulse time on | 0.1-99.9S |
| Ultrasonic pulse time off | 0.1-99.9S |
| Total Operating Time | 1-99H59M59S |
| Power regulation | 1-100% |
| Horn end diameter | F20 |
| Total length of horn | 260mm |
| Control + display mode | TFT touch screen |
| Data storage | 20 groups |
| Voice prompt + alarm function | Yes. |
| Temperature protection function | Yes. |
| Overload protection | Yes. |
| Transducer air cooling function | Yes. |
| Horn material | titanium alloy |
| Vacuum function of reaction kettle | Optional |
| Constant temperature function of reaction kettle jacket | Optional |
| Full airtight function of horn | Optional |
| Feed, discharge and temperature measurement ports | Standard |
| Power Requirements | 220V/50Hz |
| Reaction kettle material | High Borosilicate Glass |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36496/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
