Specifications
| Water tank Volume | 5L |
| Temperature range | -40~40℃ |
| temperature stability | ±0.5℃ |
| Display Accuracy | 0.1℃ |
| Environmental temperature | 5~32℃ |
| Speed range | 100-1200rpm |
| Speed regulation mode | Touch screen |
| Power supply Voltage | 200~230V |
| Display temperature mode | LED |
| setting method | Touch screen |
| safety protection | High temperature protection, over temperature protection |
| Heating power | 750W |
| refrigeration power | 450W |
| cooling Capacity | 600W |
| refrigerant | R404A |
| Mixer size | Φ8*30mm |
| Sink opening | Φ210mm |
| groove depth | 140mm |
| Maximum Capacity of reaction vessel (maximum diameter) | 1000mLΦ175 |
| Dimension | 500*450*370mm |
| Dimension | 615*565*500mm |
| Net Weight | 38kg |
| Gross Weight | 42kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36615/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
