Specifications
| kettle Capacity | 10L |
| Number of kettles | 6 |
| Cover diameter | 265mm |
| Cover length | 450mm |
| Stirring power | 140W |
| speed | 50-600rpm |
| Ultrasonic frequency | 20KHz |
| Ultrasonic maximum power | 2500W |
| Ultrasonic pulse time on | 0.1-99.9S |
| Ultrasonic pulse time off | 0.1-99.9S |
| Total Operating Time | 1-99H59M59S |
| Power regulation | Automatic adjustment + manual amplitude adjustment |
| Horn end diameter | F40 |
| Total length of horn | 250 |
| Control + display mode | TFT touch screen |
| Data storage | 20 groups |
| Voice prompt + alarm function | Yes. |
| Temperature protection function | Yes. |
| Overload protection | Yes. |
| Transducer air cooling function | Yes. |
| Horn material | titanium alloy |
| Vacuum function of reaction kettle | Optional |
| Constant temperature function of reaction kettle jacket | Optional |
| Full airtight function of horn | Optional |
| Feed, discharge and temperature measurement ports | Standard |
| Power Requirements | 220V/50Hz |
| Reaction kettle material | High Borosilicate Glass |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36633/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
