Specifications
| Discharge port diameter | Φ2.095±0.005mm |
| Discharge port length | 8.000±0.025mm |
| Barrel inner diameter | Φ9.550±0.025mm |
| Barrel length | 152±0.1mm |
| Piston rod head diameter | 9.475±0.015mm |
| Piston rod head length | 6.350±0.100mm |
| Temperature range | RT+~400℃ |
| Thermostatic Accuracy | ±0.5℃ |
| Power supply Voltage | 220V±10% 50HZ |
| Operating Environmental conditions | Environmental temperature is 10 ℃ -40 ℃; environment Relative Humidity is 30% -80%; no corrosion medium around, no strong air convection; no vibration around, no strong magnetic field interference. |
| Dimensions | 250*350*600mm |
Packing list
Host X1, relay X1, temperature sensor X2, power switch X1, heating sleeve X2, controller X1, mouth mold X1, barrel X1, printer X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36702/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
