Specifications
| Display | digital display |
| Measuring range | 10~2000000mPa·s |
| Rotor Specifications | 1#、2#、3#、4# |
| Rotor speed | 0.3/0.6/1.5/3/6/12/30/60rpm |
| Reproducibility | ±0.5%F.S |
| Measurement Accuracy | ±1% |
| Power | AC100-240V，50Hz/60Hz，DC17V1.2A |
| Data Interface | RS232 |
| Display | Digital LCD liquid crystal with blue backlight |
| Temperature transducer | RTD temperature probe |
| Weight | 7kg |
| Encasement material | Five-layer cardboard |
| Collection method | continuous acquisition |
| Capacity | 300~400ml |
| Capacity | 400Ml (self-prepared) |
| Lifting system | PE lifting system |
| Bearing system | ruby |
| Torque material | beryllium bronze |
| Control system | microcomputer |
| Encasement | aluminum alloy |
Packing list
Host x1, one rotor each for 1 #, 2 #, 3 #, and 4 #, RTD temperature probe X1, manual x1, warranty card x1.
After-sales instructions
Warranty days: 730 days
