Specifications
| power | 10-1000W continuously adjustable |
| Crushing Capacity | 0.1~700ml |
| Display | True color 7-inch touch capacitive screen high-definition display |
| Single ultrasound time | 0.1-99.9S |
| Single gap time | 0.1-99.9S |
| Total time (ultrasound + gap) | 1-99H59M59S |
| Frequency range | 20-25KHz |
| Temperature range | 0-100 ℃ (optional low temperature constant temperature) |
| Alarm function | Temperature, time, overload, no load, over temperature |
| Standard horn | F6mm |
| Optional horn | F2 、 3 、 6 、 8 、 10 、 12 、 15mm |
| Data storage | 20 groups |
| Power | 220V/110V/ 50Hz/60HZ |
| Packaging Dimensions | 427*340*168mm |
| Net Weight of ultrasonic host | 12kg |
| Ultrasonic transducer + horn net Weight | 2kg |
| Packaging Dimensions | 500*400*320mm |
| Sound box Packaging Dimensions | 385*385*585mm |
| Sound box net Weight | 13kg |
| Sound box external Dimensions | 320*320*520mm |
| Control method | MCU + TFT touch |
| Stack up and down function (saves space) | support |
| Working voice alarm and fault prompt function | Yes. |
| Ultrasonic power analog data waveform display function | Yes. |
| Ultrasonic time pulse width data waveform display function | Yes. |
| User password protection | Yes. |
| Ultrasonic host material | Aluminum alloy + ABS plastic mold one-time molding |
| Soundproof box material | Anti-corrosion board + ABS plastic mold one-time molding |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
