Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0~10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 300 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Coating rod specification | Accuracy 0.001mm, effective application width 300mm (Spreader thickness is determined according to the bar model) |
| Coater Power | Voltage 220V 50HZ |
| Coater machine Volume | 630 * 410 * 520 (L * W * H) |
| Coater Weight | Net Weight 65KG |
| speed control | Infinitely variable speed |
| Coater floor material | aluminum alloy |
| Coater Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
| Spreader Accuracy | 0.001mm |
| Coater customizable function | Jet system device, UV solid-containing device, automatic inking system |
| Oven Power | 220V 50Hz |
| Oven Power Consumption | 1000W |
| Oven Temperature range | Room temperature + 10~300 ℃ |
| Oven Temperature Fluctuation | ±1℃ |
| Oven Interior size | 450*350*450mm |
| Oven Dimensions | 620*680*620mm |
| Oven shelf (std.) block | 2 |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36923/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
