Specifications
| Lighting method | D/8 (diffuse illumination, 8 ° direction reception) SCI measurement conforms to standard CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | Φ40mm |
| Lighting source | Light spectrum LED Light source |
| spectroscopic mode | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 32 groups) |
| Wavelength Range | 400~700nm |
| wavelength interval | 10nm |
| Bandwidth | 10nm |
| Measurement range | L: 0~120 reflectance: The instrument can test the reflectance at 3 specific wavelengths specified by the user (default 440nm, 550nm, 600nm), and the APP can realize full-band wavelength display |
| Measurement caliber | Single diameter: Should 8mm (optional Should 4mm) |
| Focus method | fixed focus |
| Light-containing method | SCI |
| Color Space | CIE LAB,XYZ,Yxy,LCh |
| Color difference formula | ΔE*ab,ΔE*00 |
| Other chroma metrics | A variety of chroma indicators are realized through the APP |
| Viewing Angle | CIE 10° |
| Available Light Sources | D65,A,F2(CWF) |
| display mode | Reflectance (user-specified reflectance at 3 specific wavelengths), sample chromatic value, color difference value/graph, pass/fail result, Color simulation, Color bias |
| Display Accuracy | 0.01 |
| Measurement time | About 1.5s |
| Repeatability | Chromatic value: MAV/SCI, Delta E * ab within 0.04 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s) |
| Inter-instrument Agreement | ΔE*ab<0.35(MAV/SCI) |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| positioning method | Stabilizer positioning |
| size | 81*71*214mm |
| Weight | Approx. 460g |
| Battery life | Lithium battery, 6000 cycles in 8 hours |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Interface | USB, Bluetooth ® 5.0 |
| store data | 500 master standards, 10,000 samples, APP Mass storage |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Operating environment | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
| Optional Accessories | USB micro printer, powder test box, Bluetooth micro printer, placement base |
Packing list
Host X1, power adapter X1, data cable X1, manual X1, SQCX quality management software (official website download) X1, black and white correction box X1, protective cover X1, wristband X1, 08mm/04mm diameter X1, APP (official website download) X1
After-sales instructions
Warranty days: 1095 days
