Specifications
| Lighting method | D/8 (diffuse illumination, 8 ° direction reception) SCI/SCE measurement, in accordance with CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | Φ40mm |
| lighting source | Light spectrum LED light source, UV light source |
| spectroscopy | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 32 groups) |
| Measurement Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Half bandwidth | 10nm |
| Measurement range | L: 0~120 reflectance: 0~200% |
| Measurement caliber | Four caliber: φ 12mm, φ 8mm, φ 4mm, 1x3mm |
| Focus method | Optical inspection focus + electronic focus |
| Light-containing method | Simultaneous testing of SCI/SCE |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,βxy,DIN Lab9,DIN Lab99 Munsell(C/2) |
| color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99 |
| Other chroma metrics | WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), Isochromatic Index Mt, colour fastness, color fastness, force, occlusion, Formula Guide |
| Viewing Angle | CIE 2°/10° |
| observation light source | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum plots/data, sample chromatic values, color difference values/plots, pass/fail results, Color simulation, Color bias |
| Display Accuracy | 0.01 |
| Measurement time | Approximately 1.5 seconds (approximately 3.2 seconds for simultaneous SCI/SCE testing) |
| Sexual repeability | Chromatic value: MAV/SCI, Delta E * ab within 0.03 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s) |
| stand-alone difference | ΔE*ab<0.3(MAV/SCI) |
| measurement mode | Single measurement, average measurement (2~ 99 times) |
| positioning method | camera positioning, stabilizer positioning |
| Dimensions | 81*71*214mm |
| Weight | About 460g |
| battery life | Lithium battery, 6000 cycles in 8 hours |
| Lifetime of lighting source | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Data Interface | USB, Bluetooth ® 5.0 |
| data storage | 1000 master standards, 30,000 samples (one data can include SCI/SCE at the same time), APP Mass storage |
| operating language | Simplified Chinese, English, Traditional Chinese |
| Operating environment | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
| optional accessories | USB micro printer, powder test box, Bluetooth micro printer, placement base |
Packing list
Host X1, power adapter X1, data cable X1, manual X1, SQCX quality management software (official website download) X1, black and white correction box X1, protective cover X1, wristband X1, four caliber: 012mm + 08mm + 04mm Platform caliber X1, 1x3mm caliber X1, MOBCCS APP (official website download) X1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/36938/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
