Specifications
| number of discs | 1 |
| Disc diameter | 254mm |
| Grinding wheel speed | Stepless speed regulation 100-1000r/min Four-speed speed regulation 300 500 800 1000r/min |
| Grinding disc swirling/spinning direction | Clockwise or Counterclockwise |
| Mill motor | Brushless motor 1100W |
| Grinding head speed | 20—200r/min |
| Grinding head swirl/spin direction | clockwise |
| Grinding head motor | Stepper motor 200W |
| Timed adjustable time | 0-99min |
| Pressurization method | Single point pneumatic pressurization and midpoint pneumatic pressurization |
| pressurized pressure | Center: 35-150N Single point: 0-90N |
| Sample holding quantity | Six. |
| Specimen clamping specification | < unk > 22 < unk > 30 < unk > 45 Any specification (special specifications can be customized) |
| Power Supply | 220V 50Hz |
| Dimensions | 475*660*710mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
