SK/MIC-600-NH3-Y/100 Ammonia NH3 Gas Detector electrochemistry 0-100ppm

Detection gas ammonia NH3, detection range 0-100ppm, resolution 0.1ppm, detection principle electrochemistry, Operating Mode fixed continuous work, diffusion type, pipeline type, flow, pump suction type optional.

Model：

SK/MIC-600-NH3-Y/100

Certificate

Skyeaglee

Factory authorized direct sales

Contact

Details SPEC VIDEO CAT OI

Skyeaglee SK/MIC-600-NH3-Y/100 On-line ammonia Gas DetectorSPEC

Skyeaglee SK/MIC-600-NH3-Y/100 On-line ammonia Gas DetectorDetails

Skyeaglee SK/MIC-600-NH3-Y/100 On-line ammonia Gas DetectorPacking list

SKU: NB037006

Detection gas: Ammonia NH3

range: 0~100ppm

Resolution: 0.1ppm

Sensors principle: electrochemistry

Operating Mode: Fixed type continuous work, diffusion type, pipeline type, when circulating, pump suction type is optional.

Detection Accuracy: ≦3%（F.S）

Response time: ≦30S

output signal: Current signal output 4-20MA

Alarm method: 2 passive node signal output, alarm point can be set.

Operating temperature: -20~50℃

Relative Humidity: ≦90%RH

Working Voltage: DC12~30V

Sensors Life: 2 years

Explosion-proof method: Probe Transmitters and Sensors are flameproof

Explosion-proof sign: ExdIICT6

Connection cable: Three-core cable (single Wire diameter ≥ 1.5mm); Shielding cable is recommended

Connection distance: ≦1000 m

Protection class: IP66

Dimensions: 183*143*107mm

Weight: 1.5kg

SK/MIC-600-NH3-Y/100

On-line ammonia Gas Detector

SK/MIC-600 online gas concentration Detector is a modular design, with intelligent sensor detection technology,Flameproof (D) structure and fixed installation of flammable gas monitor. The standard configuration is a dot matrix LCD display, three-wire 4~20mA modeFit and RS485 digital signal output, optional configuration as programmable switching output and other modules, according to user needs to provide customized products, but also support output signal fine-tuning and other functions, convenient system networking and maintenance.

● On-line gas concentration Detector

● Automatic temperature compensation, zero point, full-scale drift compensation

● Automatic protection function against high-concentration gas impact

● Full software calibration function, users can also calibrate by themselves, with 3 buttons to achieve, easy to operate

● 2-wire 4-20mA output

Place of application

Paint room, incineration plant, scientific research, production workshop, company, environmental monitoring, school scientific research, building construction, fire alarm, sewageProcessing, Industrial Gas Process ControlPetroleum & Petrochemical, Chemical Plants, Smelters, Iron & Steel Plants, Coal Plants, Thermal Power Plants, Boiler Rooms, Waste Treatment Plants,Tunnel construction, oil pipelines, gas stations, underground gas pipeline maintenance, indoor air quality testing, hazardous place safety protection equipment monitoring, etc.(The data is for reference only; please also make the corresponding selection according to your actual Operating Conditions) The data shows: the usual temperature range is -20°C ~ +50°C, humidity10%RH ~ 90%RH no condensation, the absolute pressure is 106KPa±20KPa, where ±20KPa is the relative pressure, relative to the atmospheric pressureForce.

Structural diagram

Details of SK/MIC-600-NH3-Y/100 On-line Ammonia Detector Figure 1

On-line gas concentration Detector diagram Electrical wiring definition diagram (Figure 2: The main unit represents the control system such as C PLC and computer.)

Details of SK/MIC-600-NH3-Y/100 On-line Ammonia Detector Figure 2

Figure 1

Details of SK/MIC-600-NH3-Y/100 On-line Ammonia Detector Figure 3

Figure 2

Online gas concentration Detector debugging calibration diagram:

Details of SK/MIC-600-NH3-Y/100 On-line Ammonia Detector Figure 4

Series optional

Detection of gases	Range	Maximum allowed Error value	Minimum reading	When responding T90
Combustible (E_X)	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10 seconds
Combustible (E_X)	0-100%Vol	＜±3%(F.S)	0.1%Vol	≤10 seconds
Methane (CH₄)	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10 seconds
Methane (CH₄)	0-100%Vol	＜±3%(F.S)	0.1%Vol	≤10 seconds
Oxygen (O₂)	0-30%Vol	＜±3%(F.S)	0.01%Vol	≤10 seconds
Oxygen (O₂)	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤10 seconds
Oxygen (O₂)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Nitrogen (N₂)	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤10 seconds
Carbon Monoxide (CO)	0-100ppm	＜±3%(F.S)	0.1ppm	≤25 seconds
Carbon Monoxide (CO)	0-1000ppm	＜±3%(F.S)	0.1ppm	≤25 seconds
Carbon Monoxide (CO)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤25 seconds
Carbon Monoxide (CO)	0-20000ppm	＜±3%(F.S)	1ppm	≤25 seconds
Carbon Monoxide (CO)	0-100000ppm	＜±3%(F.S)	1ppm	≤25 seconds
Carbon dioxide ( CO₂)	0-500ppm	＜±3%(F.S)	1ppm	≤20 seconds
Carbon dioxide ( CO₂)	0-2000ppm	＜±3%(F.S)	1ppm	≤20 seconds
Carbon dioxide ( CO₂)	0-5000ppm	＜±3%(F.S)	1ppm	≤20 seconds
Carbon dioxide ( CO₂)	0-50000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Carbon dioxide ( CO₂)	0-20%Vol	＜±3%(F.S)	0.01%Vol	≤30 seconds
Carbon dioxide ( CO₂)	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤30 seconds
Formaldehyde (CH₂O )	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Formaldehyde (CH₂O )	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Formaldehyde (CH₂O )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Formaldehyde (CH₂O )	0-5000ppm	＜±3%(F.S)	1ppm	≤50 seconds
Ozone (O.)₃)	0-1ppm	＜±3%(F.S)	0.001ppm	≤20 seconds
Ozone (O.)₃)	0-5ppm	＜±3%(F.S)	0.001ppm	≤20 seconds
Ozone (O.)₃)	0-50ppm	＜±3%(F.S)	0.01ppm	≤20 seconds
Ozone (O.)₃)	0-100ppm	＜±3%(F.S)	0.01ppm	≤20 seconds
Ozone (O.)₃)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Ozone (O.)₃)	0-30000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Ozone (O.)₃)	0-20mg/L	＜±3%(F.S)	0.01mg/L	≤30 seconds
Ozone water (O₃)	0-20mg/L	＜±3%(F.S)	0.01mg/L	≤30 seconds
Hydrogen sulfide (H₂S )	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Hydrogen sulfide (H₂S )	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen sulfide (H₂S )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen sulfide (H₂S )	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Hydrogen sulfide (H₂S )	0-10000ppm	＜±3%(F.S)	1ppm	≤45 seconds
Sulfur dioxide (SO)₂)	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Sulfur dioxide (SO)₂)	0-20ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Sulfur dioxide (SO)₂)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Sulfur dioxide (SO)₂)	0-500ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Sulfur dioxide (SO)₂)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Sulfur dioxide (SO)₂)	0-10000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Nitric Oxide (NO)	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Nitric Oxide (NO)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Nitric Oxide (NO)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Nitric Oxide (NO)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Nitrogen dioxide (NO₂)	0-10ppm	＜±3%(F.S)	0.001ppm	≤25 seconds
Nitrogen dioxide (NO₂)	0-100ppm	＜±3%(F.S)	0.01ppm	≤25 seconds
Nitrogen dioxide (NO₂)	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Nitrogen dioxide (NO₂)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Nitrogen oxides (NO.)_X)	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Nitrogen oxides (NO.)_X)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Nitrogen oxides (NO.)_X)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Nitrogen oxides (NO.)_X)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Chlorine (CL₂)	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Chlorine (CL₂)	0-20ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Chlorine (CL₂)	0-200ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Chlorine (CL₂)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Ammonia (NH₃)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ammonia (NH₃)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ammonia (NH₃)	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Ammonia (NH₃)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Ammonia (NH₃)	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10 seconds
Hydrogen ( H₂)	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10 seconds
Hydrogen ( H₂)	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Hydrogen ( H₂)	0-20000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Hydrogen ( H₂)	0-40000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Hydrogen ( H₂)	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20 seconds
Helium ( He )	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20 seconds
Argon ( Ar )	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20 seconds
Xenon ( Xe )	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20 seconds
Hydrogen cyanide (HCN)	0-30ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen cyanide (HCN)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen chloride (HCL)	0-20ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen chloride (HCL)	0-200ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Phosphine (PH₃)	0-5 ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Phosphine (PH₃)	0-25 ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Phosphine (PH₃)	0-2000 ppm	＜±3%(F.S)	1ppm	≤30 seconds
Chlorine dioxide (CLO₂)	0-1ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Chlorine dioxide (CLO₂)	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Chlorine dioxide (CLO₂)	0-200ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ethylene Oxide (ETO)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ethylene Oxide (ETO)	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Ethylene Oxide (ETO)	0-100%LEL	＜±3%(F.S)	1%LEL	≤30 seconds
Phosgene (COCL₂)	0-1ppm	＜±3%(F.S)	0.001ppm	≤20 seconds
Phosgene (COCL₂)	0-50ppm	＜±3%(F.S)	0.01ppm	≤20 seconds
Silanes (SiH₄)	0-1ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Silanes (SiH₄)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Fluorine (F₂)	0-1ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Fluorine (F₂)	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Fluorine (F₂)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen fluoride (HF)	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen fluoride (HF)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen bromide (HBr)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ethylborane (B₂H₆)	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Hydrogen arsenide (AsH₃)	0-1ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Hydrogen arsenide (AsH₃)	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen arsenide (AsH₃)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Germanane (GeH₄)	0-2ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Germanane (GeH₄)	0-20ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrazine, hydrazine ( N₂H₄)	0-1ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Hydrazine, hydrazine ( N₂H₄)	0-300ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Tetrahydrothiophene (THT)	0-100mg/m3	＜±3%(F.S)	0.01 mg/m3	≤60 seconds
Bromine gas (Br₂)	0-10ppm	＜±3%(F.S)	0.001ppm	≤30 seconds
Bromine gas (Br₂)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Bromine gas (Br₂)	0-2000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Acetylene (C₂H₂)	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤30 seconds
Acetylene (C₂H₂)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Acetylene (C₂H₂)	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Ethylene (C₂H₄)	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤30 seconds
Ethylene (C₂H₄)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ethylene (C₂H₄)	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
acetaldehyde	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ethanol (C₂H₆O )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Ethanol (C₂H₆O )	0-2000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Methanol (CH₆O )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Methanol (CH₆O )	0-2000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Carbon disulfide (CS₂)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Carbon disulfide (CS₂)	0-5000ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Acrylonitrile (C₃H₃N )	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Acrylonitrile (C₃H₃N )	0-2000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Methylamine (CH)₅N )	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Dian Qi ( I₂)	0-50ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Styrene (C₈H₈)	0-200ppm	＜±3%(F.S)	0.1ppm	≤30 seconds
Styrene (C₈H₈)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Vinyl chloride (C₂H₃CL )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Trichloroethylene (C₂HCL₃)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Perchloroethylene (C₂CL₄)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Laughing gas (N₂O )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Nitrogen trifluoride (NF₃)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Hydrogen peroxide (H₂O₂)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Methyl bromide (CH₃Br )	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Methyl bromide (CH₃Br )	0-30000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Methyl bromide (CH₃Br )	0-200g/m3	＜±3%(F.S)	0.1g/m3	≤30 seconds
Sulfuryl fluoride (SO₂F₂)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Sulfuryl fluoride (SO₂F₂)	0-5000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Sulfuryl fluoride (SO₂F₂)	0-10000ppm	＜±3%(F.S)	1ppm	≤30 seconds
Benzene (C₆H₆)	0-10ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Benzene (C₆H₆)	0-100ppm	＜±3%(F.S)	0.01ppm	≤30 seconds
Benzene (C₆H₆)	0-2000ppm	＜±3%(F.S)	1ppm	≤30 seconds
