Specifications
| Accuracy | ±0.003mm |
| Application Film thickness range | 0~10mm scraper can be lifted and lowered |
| Application rate | 2~200mm/s |
| Coating size | 500*600mm |
| Application speed | Digital display, different speeds, |
| Vacuum aperture | F1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuumpump size | 380*180*280mm |
| Application Stick Specifications | Accuracy 0.001mm, effective Application width 300mm (Application Film thickness is determined according to the bar model) |
| Host Power | Voltage 220V 50HZ |
| Weight | Net Weight 65KG |
| Speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Optional accessories | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for Application substrate Film thickness uneven applications), film width control baffle |
| Accuracy | 0.001mm |
| Customizable functions | Jet system device, UV solid inclusion device, automatic inking system |
Packing list
Film Applicator X1, External Vacuum Pump X1, Drawdown blade X1, Imported bar X1, Product Manual X1, Opacity Chart x1 box (250 sheets)
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/37201/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
