Specifications
| Probe tip | ruby |
| Probe Type | Built-in integrated |
| Measuring range | 0 ~ 2000m |
| resolution | 0.1μ m | 1μ m | 0.01mm |
| margin of error | ±3% |
| Unit display | μm / mil |
| Measurement interval | 0.5S |
| Minimum measurement surface | F25mm |
| Minimum radius of curvature | Convex: 5mm/Concave: 25mm |
| Minimum substrate Film thickness | Fe: 0.2mm/NFe: 0.05mm |
| Power Supply | 2 x 1 5V AAA alkalinity batteries |
| Display screen | 128 X 48 dot matrix LCD |
| Operating Temperature | -20°C~50°C |
| Storage temperature | -50°C~60°C |
| Host size | 100*60*24mm |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38346/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
