Specifications
| function | Crushing, grinding, mixing, homogenizing |
| Sample type | Hard, soft, brittle, elasticity, water, fibrous |
| Feed size | ≤8mm |
| MIN discharge size | About 5-10um |
| batch throughput | ≤2x20ml |
| Regular ground time | 1-3min |
| Grinding method | Dry grinding, wet grinding, low temperature grinding, high throughput grinding |
| Number of grinding tanks | 2 |
| Grinding tank type | Screw cap tank (various material options), porous plate (PTFE) |
| Vibration speed | 60-1800r/min |
| frequency | 1-30Hz |
| Grinding time | 1s-99min59s |
| power | 250W |
| Width x Height x Depth | 300x 240x460mm |
| Net Weight | About 28kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38407/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
