Specifications
| Standard slurry Capacity | 23L |
| slurry amount | 200G - 700g absolute dry pulp (standard beating Capacity: 360g absolute dry pulp, concentration: 1.57%) |
| Knife roller size | Φ194MM×155MM |
| Rotation speed of flying knife roller | Standard beating speed 8.3 +/- 0.2 r/s; 500 +/- 10 r/min |
| Flying blade | Thickness 4.7mm, 32 pieces |
| Bottom blade | Thickness 3.2mm, 7 pieces |
| Lever arm load | 54±1N |
| Tool distance adjustment | Adjustable knife distance, manual adjustment |
| Power Supply | 380VAC,50Hz |
| Dimensions | 1260*690*940mm |
| Weight | 200kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38417/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
