Specifications
| Suitable substrate | 5~200mm |
| Speed range | 1~12000rpm |
| Speed Accuracy | 1rpm |
| Rotation speed stability | ±0.1% |
| Acceleration range | 1~10000rpm/s |
| Swirl/spin direction | Positive and reverse switching |
| glue uniformity | ±1% |
| Heating range | RT+~200℃ |
| Heating rate (chamber air temperature) | To 100 ℃ (1S), to 200 ℃ (2S) |
| Chill down | To room temperature (2S) |
| Human Machine Interface | 8 inch touch screen |
| Communication interface | USB (std.) |
| stylus | BAMBOO Resistance Pen (std.) |
| Vacuum pump | SC-550V oil-free pump |
| setup data | Unlimited sets of data, each set of 15 Rotation speed (std.) |
| Programming every time | 0~10000s |
| store data | Unlimited set of data |
| Data Protection | Default with power failure protection function |
| AC Power port of glue leveler | AC100-250V |
| Vacuum pump Power interface | AC220V (std.) |
| Power of glue leveler | 650W |
| Vacuum Pump Power | 350W |
| Pumping Speed | ≥60L/min |
| Volume of homogenizer | 340*500*250mm |
| Gluer Weight | 18KG |
| Pump Weight | 9KG |
| Environmental temperature | 0~40℃ |
| Relative Humidity | <85% |
Packing list
whole machine X1, vacuum oil-free pump x1, sheet, tray x3, power cord x1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38462/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
