Specifications
| Suitable substrate | 200~450mm/200~600mm (custom) |
| Speed range | 1~3000rpm |
| Speed Accuracy | 1rpm |
| Speed stability | ±0.1% |
| Acceleration range | 1~1000rpm/s |
| glue uniformity | ±1% |
| Human Machine Interface | 8 inch touch screen |
| Communication interface | USB (std.)/RS485 (std.)/Bluetooth (optional) |
| stylus | BAMBOO Resistance Pen (std.) |
| Vacuumpump | AP-550V no oil pump/FY oil pump |
| formula | Unlimited sets of data, each set of 15 speed (std.) or no speed (optional) |
| Every time | 0~10000s |
| Store data | Unlimited set of data |
| Data Protection | Default with power-down protection function |
| Swirl/spin direction | Can be reversed |
| AC Power port of glue leveler | AC100-250V |
| Vacuumpump Power interface | AC220V (std.) AC110V (optional) |
| Gluer power | 5KW |
| Vacuumpump power | 350W |
| Vacuumpump pumping rate | ≥60L/min |
| Volume of homogenizer | 1000*1000*1650mm |
| Gluer Weight | 200KG |
| Pump Weight | 9KG |
| Environment temperature | 0~40℃ |
| Relative Humidity | <85% |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38464/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
