Specifications
| Temperature range | -40~150℃ |
| Interior Volume | 1000L |
| Heating rate | 1.0～3.0℃/min |
| Temperature Uniformity | ≤±2.0℃ |
| Temperature fluctuation | ≤±0.5℃ |
| Temperature deviation | ≤±2℃ |
| Cooling rate | 0.7～1.0℃/min |
| Timer | 0~999h |
| Power | 380V±10% |
| Total Power | 3 ~ 13.5KW |
| Interior size | 1000*1000*1000mm |
| Dimensions | 1610*1560*1960mm |
| Inner chamber material | 1.0mmSUS304B stainless steel plate |
| Enclosure Material | Cold rolled steel plate |
| Thermal insulation material | Glass insulation cotton |
| Observation window material | Multilayer Conductive Film Tempered Hollow Glass |
| Observation window size | 200×300mm |
| test hole | 50mm |
| Air supply method | Upper air supply and lower air return method |
| Heating system | Porcelain rack nickel-chromium wire electric heater |
| Standards | GB/T2423.1-2001、GB/T2423.2-2001、GB/T10592-2008、GB/T11158-89、GB/T10589-89、IEC68-2-1 |
| Environment temperature | 5 ℃~ + 28 ℃ (average temperature within 24 hours ≤ 28 ℃) |
| Environment humidity | ≤85％R.H |
| Power | AC380 (± 10%) V/50HZ three-phase five-wire system |
| Water source requirements | Deionized water or purified water |
Packing list
Host x1, power cord X1, warranty card x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38488/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
