Specifications
| Force range | （0~500）N（50kg） |
| Accuracy grade | Level 1 |
| Test force test range | 0.4% ~ 100%FS |
| Force value Accuracy | ±0.3% |
| Indication Accuracy | Error of indication/indication variability ≤ 0.3% |
| Elongation Measurement Range | (0~400) mm (under 100mm test length) |
| Test speed error | (5~100)mm/min±0.2mm/min. |
| Clamp spacing positioning error | ±0.2mm |
| Moving collet reset error | ±0.05mm |
| Force resolution | 0.01N |
| Force unit | N, g, kg, Lb, kpa and other units |
| Deformation resolution | ≤0.1mm |
| Fixture width | 18Mm (Miscellaneous size can be customized) |
| clip spacing | The test length is (1~ 400) [can be customized] |
| stretching speed | 1~ 500mm/min stepless speed regulation |
| return speed | 150mm/min stepless speed change [ (1~ 550) mm/min adjustable] |
| Drive screw | Adopt Taiwan, China single-column structure precision ball screw |
| Test method | Using the drop-down Test method, |
| motor | Stepper motor, 0~500mm/min stepless speed change |
| Human Machine Interface | 7.0In touch screen control with Linear dispersion display |
| printout | Built-in modular integrated thermal printer |
| Communication output | Built-in R232 interface, optional connection to computer |
| Size/Weight | 400×300×800 mm、About60kg |
| Power | 220v、50Hz |
Packing list
Complete machine X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
