Pushen SLZ-20/30 Cube Applicator 20μm/30μm

SLZ 20/30um

fixture

Cube, Film thickness 20/30um, Spreader width 12.7mm, accuracy +/- 2μm/+/- 3μm, 1Cr17N2 material.

The Square Applicator is available in two sizes. The Square Applicator can accurately apply film in a single row.

Ideal for preparing samples for use with a Linear Drying Time Recorder, or for comparing different formulations simultaneously. Each Cube Film Applicator provides 2 film thicknesses.

use

It is used to coat a wet film with a specified thickness to measure the hiding power, color and luster of the sample or to prepare a sample, etc.

Instructions

Place the template on the platform and secure it so that it does not move as the preparer slides over it. According to the required wet film thickness, select the preparer, place it on the short side of the sample, close to parallel or at a specified position, then pour about 5ml of the sample on the front of the preparer, press its two ends with your fingers, Gliding at a constant speed per second, that is, coating into a wet film of required thickness. After use, wash and dry with solvent, and coat the surface with lubricating oil.

Standards

ASTMD 823

Packing list：Applicator X1, Encasement Box X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
