Specifications
| Control method | Touch screen + buttons |
| display mode | KN and MPa display simultaneously |
| Measurement range | 0~10KN |
| Resolution | 0.001kN |
| Accuracy grade | 0.5%F.S |
| Displacement range | 50mm |
| Displacement resolution | 0.01 mm |
| stretching speed | 4~ 14mm/min (adjustable) |
| LCD display | 3.5 inch touch screen |
| Data storage | 2200 articles |
| peak hold | support |
| Linear dispersion display | Force value intensity value and time display |
| Fixed load value function | support |
| numerical correction | 10-segment polyline |
| Power Supply | 12V lithium battery |
| host material | LightWeight aluminum alloy |
| Host Weight | 4.9kg |
Packing list
Host X1, charger X1, manual X1, certificate X1, warranty card X1, combination glue X1 box, riveting box 6-8-10 each X1, 100X100 standard block X5, 45X95 standard block X5
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38539/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
