LANDTEK CM8820 (5mm Range) Cladding Thickness Gauge, Large Range Customized Type

CM8820 (5mm range)

Thickness Gauge (customized)

Measurement range 0~5mm, error range +/- 5%, resolution 0.1μm | 1μm, widely used in the measurement of steel, iron and other ferromagnetic metal substrates on non-ferrous magnetic coatings, platings.

Introduction

CM8820 cladding Thickness Gauge adopts magnetic induction measurement method, and the measurement range is 0~2000μm (0~5mm is customized for large range). CM8820 cladding Thickness Gauge uses a magnetic sensor to measure non-ferromagnetic coatings and coatings on ferromagnetic metal substrates such as steel and iron, such as: paint, powder, plastic, rubber, synthetic materials, phosphating, chromium, zinc, Lead, aluminum, tin, cadmium, porcelain, enamel, oxide layer, etc.

Note: CM8820 cladding Thickness Gauge can customize different measurement ranges (2mm-6mm) according to the user's measurement range requirements, please consult the mall engineer for details.

Application

 Coating Thickness Gauge CM-8820 (5mm range) uses a magnetic sensor to measure non-ferromagnetic coatings and coatings on ferromagnetic metal substrates such as steel and iron, such as: paint, powder, plastic, rubber, synthetic materials, phosphating layer, chromium, zinc, lead, aluminum, tin, cadmium, porcelain, enamel, oxide layer, etc.

Features

Measuring the thickness of non-magnetically permeable coatings on ferromagnetic metal substrates

Pictures

LANDTEK Coating Thickness Gauge Selection List

Packing list：Host x1, measurement probe x1, reference block (iron base) CTG-BSx1, calibrated diaphragm CTG-CFx4, portable box x1, manual x1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
