Specifications
| Specifications | 5L |
| Speed adjustment range | 20~140rpm |
| Water evaporation Capacity | 2L/h |
| Temperature adjustment range | Water: RT + 5~ 99 ℃ Oil: RT + 5~ 180 ℃ (optional) |
| Temperature Accuracy | ±1℃ |
| safety protection | Motor overcurrent protection, liquid expansion overtemperature protection, leakage protection, induction anti-dry burning protection |
| Display | Digital display |
| Sink lifting method | Electric lift |
| Heating power | 2300W |
| Condensation area | 0.28M2 |
| Swirl/spin bottle | 5L |
| Collection bottle Volume | 3L |
| Sealing ring | PTFE Teflon coating corrosion resistant sealing pad |
| Lifting stroke | 150mm |
| bracket | Brackless |
| size | Diameter 365mm * 225mm |
| Chill down circulation port (OD) | 14mm |
| Dimensions | 860*410*1120mm |
| Power Supply/frequency | 220V 50HZ/60HZ |
Packing list
host x1, instruction manual x1, packing list x1, certificate x1.
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38704/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
