Specifications
| Maximum flow | 125L/min |
| Pump head type | Two-stage pump (PTFE material pump head) |
| Ultimate Vacuum | 15-20 mbar |
| Maximum operating pressure | 1bar |
| Vacuum adjustment | No vacuum regulating valve |
| Interface Specifications | 12mm |
| Pump head material | PTFE material |
| Composite diaphragm material | PTFE composite diaphragm material |
| Disc material | FFPM |
| Duty Cycle | Can work continuously |
| Environment Relative Humidity | <80%RH |
| Medium and environment temperature | 5 ℃ ～ 40 ℃ |
| Motor rated speed | 1450RPM |
| Dimensions | 380*300*200mm |
| Rated power | 600W |
| Power | AC 220V 50HZ |
Packing list
host x1, instruction manual x1, packing list x1, certificate x1.
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38710/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
