Specifications
| Storage tank Volume | 3L |
| No-load minimum temperature | -20℃ |
| Temperature range | -20~20 ℃/(without heating) |
| temperature stability | +/- 2 ℃ (can be set +/- 0.5 ℃) |
| Cooling Capacity (10 ℃) | 450w |
| refrigerant | R404A |
| Temperature transducer | pt100 |
| Controller display | liquid crystal |
| External connection port | USB/R485 (optional) |
| safety protection | Refrigerator delayed start, complete-built unit leakage, overcurrent, overVoltage protection |
| Complete-built unit power | 500W |
| Power | AC220V±10%/50HZ |
| Circulating pump power | 30W |
| Maximum flow rate of circulating pump | 9L/min |
| head | 9m |
| Liquid inlet and outlet diameter | f12mm |
| Complete-built unit noise | ≤ 45 |
| Total Weight | 35Kg |
| Tank opening/depth φ × H | F180 × 120mm |
| Dimensions | 250 * 480 * 550mm (including wheels) |
| Suitable for rotary steamer (Volume * number of units) | 2L×1 |
Packing list
host x1, instruction manual x1, packing list x1, certificate x1.
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38714/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
