Specifications
| Tank Volume | 30L |
| No-load minimum temperature | -20℃ |
| Temperature range | -20~20 ℃/(without heating) |
| temperature stability | ±2℃ |
| Cooling Capacity (10 ℃) | 4000w |
| refrigerant | R404A |
| Temperature transducer | pt100 |
| Controller display | liquid crystal |
| External connection port | USB/R485 (optional) |
| Safety protection | Delayed start of the refrigerator, leakage of the whole machine, overcurrent, overVoltage protection |
| Rated Power | 3600W |
| Power | AC220V±10%/50HZ |
| Power of circulating pump | 65W |
| Flow rate of circulating pump | 45L/min |
| head | 4.6m |
| Liquid inlet and outlet pipe diameter | Φ14mm |
| Whole machine noise | ≤ 70 |
| Machine Weight | 100Kg |
| Tank opening/depth φ × H | Φ350×350mm |
| Dimensions | 455 * 705 * 975Mm (including wheel feet) |
| Suitable for rotary steamer (Volume * number of units) | 5L×1 |
Packing list
host x1, instruction manual x1, packing list x1, certificate of conformity x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38718/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
