YIHENG IT-08B3 heating Magnetic Stirrer (disc type) working disc temperature control

IT-08B3

Magnetic Stirrer (Disc Type)

Heating model, working plate temperature control up to 320 ℃, accuracy +/- 15 ℃, stirring capacity up to 3kg, aluminum alloy shell, microcomputer control, with temperature protection and anti-scalding warning light.

Product Description

The magnetic stirrer is driven by a micro-motor to rotate a high-temperature-resistant strong magnet to generate a rotating magnetic field to drive the stirrer in the container to rotate, thereby stirring, mixing or auxiliary heating the liquid in the container so that the solution can be fully mixed at the set temperature. It can be widely used Used in biology, medicine, chemistry and other fields.

Features

● LCD, menu-style operation interface, parameters such as temperature, speed and countdown are displayed on one screen, which is easy to understand and easy to observe and operate.

● Equipped with microcomputer control technology, it ensures that the rotation speed remains constant when the stirring viscosity is constantly changing.

● The aluminum alloy die-casting shell has the characteristics of high temperature resistance, corrosion resistance and easy cleaning.

● The base material of the heating table is aluminum alloy, and the exterior is sprayed with composite material coating, which not only has good heat conduction effect, but also has corrosion resistance. The smooth mixing table is easy to clean and has no pollutants.

● Large output torque, suitable for stirring solutions with low viscosity and large volume or high viscosity and small volume. (Different models have different volumes)

● An anti-corrosion liquid guiding groove is designed on the top of the control panel, even if the liquid overflows during the stirring process, it will not cause damage to the electronic components in the agitator.

● The heating platform adopts a disc, which concentrates the heat, and is more suitable for heating and stirring round beakers and Erlenmeyer flasks.

● Adopting brushless DC motor, the operation is more stable, the life is longer, and the speed control is more precise.

safety protection

● Temperature deviation protection: 08A/B series will stop heating when the measured temperature exceeds a certain value of the set temperature (10°C-30°C).

● Anti-scalding warning light: 08A/B series work plate temperature exceeds 55 ℃, the indicator light flashes to remind users not to touch the work plate.

● Special protection: anti-scald cover (optional, price: 600 yuan).

Disc type stirrer classification

● Constant temperature magnetic stirrer: IT-08A series external temperature sensor can directly measure and control the temperature of the liquid in the container, and the temperature control is accurate and reliable.

● Heating magnetic stirrer: IT-08B series monitors and controls the temperature of the heating table.

● Magnetic stirrer: IT-08C has no heating function.

Packing list：host x1, instruction manual x1, packing list x1, certificate x1.

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
