Specifications
| Temperature range | -10~100℃ |
| Temperature control method | Smart PID |
| Temperature fluctuation | ±0.05~0.1℃ |
| Temperature Resolution | 0.1℃ |
| Tank Volume | 8L |
| Tank opening Dimensions | 175*145*150mm |
| number of holes | 1 |
| Circular mode | Internal/external circulation |
| Pump flow | 12L/min |
| Maximum pump pressure | 0.2bar |
| Maximum suction of pump | 0.1bar |
| Power Supply | 200~230，VAC |
| Dimensions | 415X410X426mm |
| Temperature display mode | LED |
| heating power | 2000W |
| Cooling Capacity 10 ℃ | 300W |
| Pump type | Pressure/suction pump |
| Pump connection interface | M16x1 |
| Instrument fixing method | desktop |
| Allow continuous operation | 100% |
| Allowable environment temperature | 5~32℃ |
| Allowable Relative Humidity | 80% |
| frequency | 50Hz |
| meet the standard | JJF 1030-2010 |
Packing list
Complete-built unit x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38902/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
