Specifications
| Air supply method | forced convection |
| Temperature range | No humidification: 0~65 ℃; with humidification: 10~65 ℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | High temperature +/- 0.5 ℃; Low temperature: +/- 1 ℃ |
| Temperature Uniformity | ±1℃ |
| Humidity Control Range | 45%~90%RH |
| Humidity stability | ±5% |
| Liner material | stainless steel plate |
| Enclosure Material | Cold rolled steel plate, surface resistant painting |
| heat insulation material | polyurethane |
| Heating device | Stainless steel heating pipe |
| Rated power | 1.0kw |
| compressor | Air-cooled closed compressor |
| refrigerant | R134A |
| Defrost structure | Type B: manual; Type BX: automatic |
| Humidity control mode | automatic |
| Lead Hole | Inner diameter 52mm each |
| Controlled external Power Supply | 1 external |
| Temperature Control mode | 30-Segment LCD program |
| Temperature setting method | Tap the button to set |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Timer Range | 0~99.9h × 30 (with Timer and waiting function) |
| Operational Features | Fixed value, operation, scheduled operation, automatic stop/appointment start, program operation |
| programmable function | Standard |
| Sensors | Pt100 |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage, memory |
| Safety Devices | Overrise alarm, overload protection |
| Liner size | 500*400*750mm |
| Dimension | 640*620*1270mm |
| packing size | 820*760*1430mm |
| Volume | 150L |
| Shelf load bearing | 15kg |
| Shelf (max.) | The ninth floor. |
| Shelf spacing | 60mm |
| Power supply Voltage | AC 220V/3.6A（50/60Hz） |
| Net Weight | 86kg |
| Shelf (standard) | 2pcs |
| Shelf | 4 pieces |
| Optional Accessories | Shelf, RS485 interface, printer, recorder, external communication, remote control, programmed temperature control, wireless SMS alarm, U disk data storage |
| Gross Weight | 114kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38908/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
