LEICI DZS-706F multiparameter analyzer

DZS-706F

Multiparameter analyzer

pH/pX level 0.01, conductivity level 1.0, test items: pH/pX value, Ion concentration, mV value, conductivity, Electrical resistivity, TDS, salinity, dissolved oxygen, dissolved oxygen saturation, temperature

main feature

● Adopt high-definition LCD with clear display

● Temperature units are optional: ℃ and °F.

●Supports functions such as power-on self-diagnosis, automatic shutdown, power-off protection and factory reset

● Support firmware upgrade function, allowing function expansion and personalized requirements

●Support IP54 protection level

● Standard configuration of three-composite pH electrode, composite conductivity electrode, polarographic dissolved oxygen electrode, electrode holder, dust cover and calibration solution

One machine for multiple purposes

● Built-in 3 measuring units of pH/pX, conductivity and dissolved oxygen

● Test items: pH/pX value, ion concentration, mV value, conductivity, resistivity, TDS, salinity, dissolved oxygen, dissolved oxygen saturation, temperature

Intelligent detection and automatic identification

● Intelligent end point determination: supports automatic reading, scheduled reading, scheduled interval reading, and manual reading

●Support automatic temperature compensation, automatic calibration, and electrode diagnosis

Data management, information traceability

● Support data storage (500 sets each), review, deletion, transmission and printing

● Comply with GLP and realize data traceability

● Equipped with RS-232 interface, supports connection to standard RS-232 serial port printer, and directly prints measurement results. The printing format is optional.

● With USB interface, it can be connected to PC through special communication software to realize data transmission.

pH/ion measurement function:

● Automatically identify multiple groups of buffer solutions such as GB, DIN, and NIST, and support customization of standard solutions and standard solution groups, with up to 5 points of calibration.

● Built-in Na+, K+, NH4+, Cl-, F- and other ion modes, allowing users to create their own

● Rapid switching of multiple ion concentration units such as μg/L, mg/L, g/L, mol/L, mmol/L, and PX

●Measurement mode: direct reading concentration method measurement

Conductivity measurement function:

● Within the range, it has functions such as automatic temperature compensation and automatic range switching.

● Automatically identify conductivity standard solutions and support 1-3 point conductivity electrode calibration

●Supports multiple conductivity compensation methods such as non-compensation, linear, pure water compensation, etc.

● Reference temperature 20℃ or 25℃ optional

● Supports automatic frequency switching, and is equipped with a 1.0 constant electrode that can cover the full range of measurements (it is recommended to use a 0.1 constant or 0.01 constant conductivity electrode for measurement of samples below 20 μS/cm)

Dissolved oxygen measurement function:

●Supports automatic temperature compensation and automatic atmospheric pressure compensation (units optional: kPa, mbar, Torr, Atm)

● Support zero oxygen calibration and full scale calibration

●Support manual salinity compensation function

Packing list：Host X1, E-301-QC type pH three, compound, electrode X1, DJS-1VTC type Conductivity detector electrode X1, DO-958-Q type dissolved Oxygen electrode X1, pH bagged buffer solution (3 * 10) X1, conductivity solution 1408μs/cm (1 * 10) X1, multifunctional electrode holder X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
