Specifications
| Maximum test force | 50KN |
| Effective Measurement Range | 2% to 100% of full scale |
| Test force Accuracy | +/- 1% better than indication |
| Displacement measurement Accuracy | +/- 1% better than indication |
| Displacement resolution | 0.01mm |
| Beam displacement speed | 0.05-500 mm/min stepless speed regulation |
| Speed Accuracy | +/- 1% better than indication |
| Effective test width | 1050mm |
| Host Power | 220V 50Hz |
| Power | 1.5KW |
| Dimensions | 1600mm*1000mm*4200mm (L * W * H) |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
