Specifications
| Display type | 1000KN；100000kg；220000lb |
| Load Graduation | 0.1KN；10Kg；100lb |
| Sensors structure | external |
| Precision level | Level 0.5 |
| error of indication | ≤±0.5% |
| Power Supply | Lithium Battery: 3.7V/1000mAh |
| unit | N、KN、Kgf、gf、lbf、tf |
| Charger | AC Input：220V/50HZ、DC Output：5V/1A |
| Operating temperature | 0℃~40℃ |
| Storage temperature | -20℃~70℃ |
| Relative Humidity | 15%~80% |
| Operating Environment | No vibration and corrosion medium around |
| Installation size | 40Mm * 80mm screw hole: 4-M4 (instrument) |
| Dimension | 208Mm * 70mm * 41mm (instrument) |
| Net Weight | 0.36Kg (instrument) |
Packing list
Force Gauge x1, Certificate of Conformity x1, Warranty Card x1, Manual x1, Instrument Case x1
After-sales instructions
Warranty days: 365 days
1. Warranty: one year
2. Within one month after purchase, if there is a product quality problem under normal use and no damage to the appearance, the product of the same model and specification can be replaced with the invoice, valid warranty card and complete packaging;
3. There is no warranty for man-made failure or customer disassembly;
4. Products beyond the warranty period can be repaired by the original factory.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3896/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
