Specifications
| video capture | China's high-end industrial camera |
| Maximum image resolution | 2048 * 1536 pixels |
| video output | USB2.0 output, computer control gain, luminance, exposure time. USB Power Supply, no separate Power Supply. |
| Signal-to-noise ratio | >52dB |
| exposure time | 17uS~2.3S |
| Lens characteristics | China High-end Zoom Microscope Head |
| Zoom Ratio | 0.7~4.5X |
| magnification | 30~130 times |
| Best shooting distance | 95mm |
| tube length | 165mm |
| Lens Adjustment Stand Features | Adopt F-type special lens holder, adjustment range: 60mm |
| Stage mobile | Manual, smooth Optical inspection parts X direction (horizontal): 80mm, Accuracy 0.1mm; Y direction (vertical): 30mm, Accuracy 0.1mm; Z direction (up and down): 50mm |
| Swirl/spinning table characteristics | China high-precision Optical inspection swirl/spin table, driving the stage concentric swirl/spin to realize the turning method to test the forward and backward angles |
| Swirling/spinning | Computer control, high-subdivision stepper motor drive, and manual adjustment |
| Rotation angle | ≥90° |
| Swirl/spin speed | Computer software adjustment |
| Light source | Light source with monochromatic semiconductor illumination, continuously adjustable luminance |
| maximum frame rate | 25 frames per second |
| Dimension | 600*310*450mm |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38968/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
