Specifications
| camera | Industrial camera |
| Color Mode | color |
| Maximum resolution | 2048 * 1536 pixels |
| Minimum resolution | 640 * 480 pixels |
| video frame rate | Up to 25FPS |
| Zoom Ratio | 0.7~4.5X |
| working distance | 95mm |
| tube length | 168mm |
| Field of view | 18mm |
| Focusing bracket | F-type focusing bracket, adjustment range: 60mm |
| Download the mobile mode of the object stage | Manual, smooth Optical inspection parts |
| upper stage | Size: 70 * 45mm, rounded corners on one side |
| Injection mechanism | Automatic sampler |
| Injection resolution | 0.01uL |
| Injection method | Continuous injection, quantitative injection, continuous withdrawal, quantitative withdrawal |
| injection rate | Continuously adjustable |
| Sample injector Volume | 500uL/1000uL |
| Backlight | Semiconductor Cold Light source, continuously adjustable |
| Dimension | 570*190*280mm |
| Weight | 8.5kg |
| Power supply Voltage | AC220V 1A |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/38969/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
