Specifications
| X/Y trip | 500×400mm |
| Z-axis lift | 150mm |
| Glass table | 560×460mm |
| Product Structure | Base, column, mobile workbench are made of high-precision granite |
| lighting system | Light source and transmission Light source with LED, adjustable luminance |
| CCD camera | 1/3 high-definition color CCD camera (Miscellaneous brand can also be selected as required) |
| magnification | Step Zoom Optical inspection magnification: 0.7~ 4.5X, image magnification: 30~225X |
| Measurement Accuracy | （3+L/200）μm |
| resolution | 0.001mm |
| Repeatability | 0.002mm |
| Operation mode | Computer automatic control stroke |
| Power | 220V(AC) / 50HZ |
| Recommended environment | Temperature: 19~ 24 ℃, Humidity: 45%~ 75% |
| Optional accessories | Z-axis image altimetry or optional British Reishaw probe contact measurement |
Packing list
Imager host X1, dedicated industrial control computer X1, genuine software X2, axis grating ruler X1, linear guide X1, freeze frame fixed lens X1, high definition CCD camera X1
After-sales instructions
Warranty days: 365 days
