Defelsko PosiTector GLS60-3 Single Angle Glossmeter Advanced

GLS60-3

Glossmeter

Premium 25W reading + real-time graphics + 2 scan modes + rich Interface, 60 ° for most Gloss applications, Measurement range 0~2000Gu, Repeatability +/- 0.2 GU (< 100 GU ), +/- 0.2% (> 100 GU), reproducibility +/- 0.5 GU (< 100 GU ), +/- 0.5% (> 100 GU), 1000 reading storage

The PosiTector GLS Gloss Meter (GLS) is a handheld electronic instrument used to measure the specular reflectance and gloss of a surface. It consists of a body (standard or advanced) and a probe.

Features

Simple

Fast measurement speed – 60+ readings per minute

Larger 2.8-inch impact-resistant color touchscreen with redesigned keypad for quick menu navigation

The help explanation menu item on the meter is just the touch of a button

The RESET function immediately resets the factory settings

powerful

The statistical mode continuously displays/updates the mean, standard deviation, min/max, and number of readings while measuring

Screenshots – Save 100 screen images for recording and view HiLo alarms, audible and visible alarms when measurements exceed user-specified limits – can be used as pass/fail for quick checks

Instant-start feature for quick gage start in the event of a recent power outage 30% longer battery life

The USB port allows for a quick and simple connection to a PC and continuous power delivery. USB cable included

Use the PosiSoft USB drive to view pre-formatted reports and .csv data—no software installation required

Each stored measurement is stamped with a date and time stamp

Includes PosiSoft software for viewing and reporting data

Software updates over the web keep your gages in the new state

durable

All-metal probe construction for long-term stability

Weatherproof, dustproof and waterproof instrument body – IP65-rated housing

Ergonomic design with durable rubber handles

Rugged indoor/outdoor instruments – perfect for field or store use

Shock-absorbing protective rubber holster for increased impact resistance

accurate

The calibration certificate shows that the probe and gloss standards are traceable to the NRC

Using a protective substrate with an integrated calibration standard (tile), automatic diagnostics and automatic calibration at start-up

Store multiple calibration standards (tiles) for quick calibration adjustments

Complies with national and international standards, including ISO and ASTM

versatility

The PosiTector body accepts all PosiTector probes and can be easily converted into a coating thickness gage, dew point meter, soluble surface profiler, soluble salt Tester, Hardness Tester, or ultrasonic wall thickness meter

Selectable units for each geometry – glossiness and reflectance percentage

Auto-rotate display with flip lock

Selectable display language

Model selection

PosiTectorGLS 60°

■ Suitable for most gloss applications,

Selectable angle for half light

PosiTector GLS 20/60°

■Suitable for high-gloss to semi-gloss applications

■Calculation of haze (haze index)

PosiTector GLS 20/60/85*

■Suitable for high-gloss, semi-gloss, matteapply

■Calculation of haze (haze index)

- Standard model

Includes all the features shown on the left side plus...

Each probe can store 1,000 readings

- Advanced models

Includes all the features shown above plus...

Store 250,000 readings in up to 1,000 batches and sub-batches

Differential mode automatically calculates the difference between the current reading and the stored reference value

2 powerful scanning modes for quantifying large surfaces

• Normal – continuous reading

• Statistics – Take continuous readings as you scan and record averages, standard deviations, min/max, and number of readings

Real-time graphs of measurement data

Touchscreen keyboard for quickly renaming batches, adding notes, and more

WiFi technology syncs wirelessly with PosiSoft.net and downloads software updates

Bluetooth 4.0 technology for data transfer to mobile devices running the PosiTector app or optional portable printer. The BLE API can be used for integration into third-party software.

Integrate with third-party software, drones, ROVs, PLCs, and robotic devices using a variety of industry-standard communication protocols

Packing list：Host X1, glossmeter probe X1, protection base X1 with integrated Calibration plate, cleaning cloth X1, rubber protective cover X1, wristband X1, No. 7 battery X3, USB data cable X1, Chinese and English manual X1, factory certificate X1, instrument case X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
