Specifications
| Display mode | digital explicit |
| Measurement range | 100~320000000mPa·s |
| Rotor speed | 0.1~100rpm |
| Reproducibility | ±0.2%F.S |
| Measurement Accuracy | ±1%F.S |
| measurement mode | Manual, automatic stop time, automatic viscosity stop mode, programming mode (up to 40 segments) |
| Measurement Mode Storage | 10 of the above measurement modes |
| Measuring unit | %/mPa·s/Pa·s/kPa·s/ (真 つ cP/P) |
| Measuring temperature | 10~60℃ |
| input and output model | USB A terminal (for connecting serial printer), USB B terminal (for connecting PC), for connecting temperature sensor (optional), external connection terminal (measurement start/end signal) |
| Temperature Resolution | 0.1℃ |
| Temperature Accuracy | ±0.2℃ |
| Zero Setting | Yes. |
| Range setting | Yes. |
| Environmental temperature | 0~40℃ |
| Environmental humidity | Relative Humidity less than 90% (no condensation) |
| Power | AC100~230v 50/60Hz (the limit load of the standard power cord is AC125V) |
| current consumption | 15VA |
| Contact with liquid part | stainless steel |
| Host size | W300*334*436mm |
| Weight | About 6.5kg (including base bracket), base bracket about 2.4kg |
| third gear | H、R、U |
| Full scale torque | 718.7μN·m、1437.4μN·m、5749.6μN·m |
| Segmented range of different gears | 100~40000mPa·s、100~80000mPa·s、400~320000000mPa·s、100~320000000mPa·s |
| Rotation speed Control mode | Progressive growth of 0.1RPM, a total of 1001 segments |
Packing list
Viscometer x1, standard tapered rotor x1, sample cup x1, sample cup placement table x1, bottom seat bracket x1, main unit storage box x1, tapered rotor storage box x1, instruction manual x1.
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39066/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
