Specifications
| Coating method | Bar + automatic inking system |
| Mayer Rod Thickness Range | 1-571.5 μm (Spreader thickness according to bar model) |
| Mayer Rod Accuracy | ±0.001mm |
| Coating speed | 5-200Mm/s (< 5mm/s can be customized) |
| Coating size | 600 * 800Mm (Miscellaneous size can be customized) |
| Spreader distance control | The number can be set arbitrarily within the range of 1-800mm |
| Vacuum Area | 600 * 800Mm (can be customized) |
| vacuum aperture | Φ0.7mm |
| Vacuum hole spacing | 10*10mm |
| Vacuum pump size | 380*180*280mm |
| speed control | Infinitely variable speed |
| Substrate clamping method | Vacuum adsorption |
| Control mode | Touch screen control |
| Bottom plate material | aluminum alloy |
| Spreader Accuracy | ±3μm |
| Heating Temperature range | RT+~180℃ |
| Temperature Uniformity | ±3℃ |
| Heating mode | Baseplate heating |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2-150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Shaft transmission mode | Timer belt |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ 8 (self-equipped) |
| Power Voltage of charging system | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum Volume | 1L |
| Dimension | 1022*810*630mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Film Applicator X1, External vacuum pump X1, imported bar X2, automatic inking system x1, product manual X1
