Specifications
| length | 1500Mm (can be customized) |
| Network bandwidth | 300Mm (can be customized) |
| Curing Oven Appearance | Black/Self (can be customized upon request) |
| Mesh belt material | Teflon/PVC |
| Maximum speed | 6-8 meters/min |
| roller | Galvanized roller surface knurling |
| Sport mode | forward rotation |
| Input power | AC220V 50/60Hz |
| Ambient Operating Temperature | 0-40℃ |
| relative temperature | 20-90% |
| Curing Oven Weight | 45KG (subject to actual situation) |
| Appearance of LEDUV curing lamp | rose gold |
| Lamp holder Dimensions | 295*50*60mm |
| Chill down | water cooling |
| Chip brand | Seoul |
| control mode | 24v |
| wavelength | 395nm |
| power | 700w |
| luminous size | 280*30mm |
| optical power | 12W/cm2 |
| lifespan | 20000H |
| irradiation distance | 30~50mm |
| power control | 0% -100% adjustable |
| input Voltage | 220V |
| Appearance of water cooler | black and white |
| Water cooler Dimensions | 550*280*430mm |
| compressor | Yes |
| Temperature range | Adjust freely within the range of 5-35 ℃ |
| power | 200W |
| head | 28m |
| Volume | 13.5L |
| circulating water flow | 8L-35L/min |
| Whole machine noise | ≤45dB(A) |
| Machine Weight | 40KG |
| input Voltage | 220v |
| energy | 3000-5000mJ/cm2 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39080/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
