Specifications
| Lighting method | 45/0 (45 annular uniform illumination 0 ° reception); conforms to standard CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | F40mm |
| lighting source | Light spectrum LED light source, UV light source |
| Spectroscopic method | Plane grating spectroscopy |
| sensor | 256-Pixel dual array CMOS image sensor |
| Measurement Wavelength range | 400~700nm |
| wavelength spacing | 10nm |
| Half Bandwidth | 10nm |
| Reflectance Measurement Range | 0~200% |
| Measurement caliber | 定制单一口径：LAV:Φ18mm/Φ20mm;MAV:Φ8mm/Φ10mm；SAV:Φ4mm/Φ5mm |
| Light-containing method | 45/0 |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,HunterLab,βxy,DIN Lab99 Munsell(C/2) |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99,ΔE(Hunter) |
| Other chromaticity indicators | WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), Isochromatic Spectrum Index Mt, lightfastmess, color fastness, force, coverage, 555 hue classification |
| Viewing Angle | 2°/10° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum graphs/data, sample chromatic values, color difference values/graphs, pass/fail results, Color simulation, Color bias |
| Measurement time | About 1.8s |
| Sexual repeability | Chromatic value: MAV/SCI, ΔE * ab within 0.02 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s) |
| Inter-station difference | ΔE * from < 0.15 (MAV / SCI) |
| Measurement method | Single measurement, average measurement (2~ 99 times) |
| Positioning method | / |
| size | 370*240*260mm |
| Weight | About 7.8kg |
| Power Supply | DC 24V, 3A power adapter Power |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 7.0inch, capacitive touch screen |
| Data Interface | USB, Bluetooth ® 5.0, trigger switch interface |
| Store data | 1000 master standards and 30,000 samples |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Operating temperature range | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage temperature range | -20~50 ℃, 0~85% RH (no condensation) |
| Optional accessories | Micro printer, foot switch, swirl/spin stand |
Packing list
Host X1, power adapter X1, data cable X1, quality management software (official website download) X1, black and white correction box X1, protective cover X1, measurement diameter X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39088/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
