Specifications
| Lighting method | 45/0 (45 annular uniform illumination 0 ° reception); conforms to standard CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Lighting source | Light spectrum LED Light source, UV Light source |
| spectroscopy | Concave grating spectroscopy |
| Sensor | 256 pixel dual array CMOS image sensor |
| Wavelength Range | 400~700Nm/10nm output |
| Reflectance Measurement Range | 0~200% |
| non-contact distance | 7.5mm(±0.2mm) |
| Sample height | Unlimited thickness, only test probes are used |
| Distance adjustment method | Fixed height according to actual sample |
| Measurement mode | Software customization capabilities (additional customization capabilities need to be evaluated) |
| positioning method | camera positioning |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,Musell,s-RGB,HunterLab,βxy,DIN Lab99 |
| Color difference formula | ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE（Hunter），DINΔE99 |
| Other chroma metrics | WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), homochromatic index MI, colour fastness, color fastness, force, coverage |
| Viewing Angle | 2°/10° |
| Available Light Sources | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4，F5，F6,F7(DLF),F8,F9，F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum graph/data, sample chromatic value, color difference value/graph, Color simulation, pass/fail results, display tolerance can be set |
| Measurement time | Fastest 0.2s |
| store data | 18,000 sample mode + quality control mode 30,000 continuous statistical mode, no more than 48,000 in total |
| Repeatability | Optimal test mode (Measurement time 1.5 seconds): Spectral reflectance: standard deviation within 0.1%: chromatic value: Delta E * ab within 0.03 (after preheating, the average value of 30 whiteboard measurements at intervals of 5s) |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| size | 200 * 200 * 160Mm (test probe) |
| Weight | Approximately 3Kg (test probe only) |
| Power Supply | DC 24V, 3A power adapter Power |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 7inch, capacitive touch screen |
| Interface | USB, Bluetooth ® 5.0 |
| Operating language | Simplified Chinese, Traditional Chinese, English |
| Operating temperature range | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage temperature range | -20~50 ℃, 0~85% RH (no condensation) |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
