Specifications
| Measurement mode | Optical rotation, specific rotation, concentration, sugar content and custom formula |
| light source | LED Cold Light source + high-precision Interference filter |
| Working Wavelength | 589.3nm |
| test function | Single, Multiple, Continuous Measurement modes |
| Measurement range | Optical rotation +/- 90 ° sugar content +/- 259 ° Z |
| minimum reading | 0.001° |
| Accuracy | ±0.004° |
| Temperature range | 10 ℃ -55 ℃ (Paltier temperature control) |
| Temperature Resolution | 0.1℃ |
| Temperature control Accuracy | ±0.1℃ |
| Display mode | 8 inch TFT true color touch screen |
| Standard testtube | 200Mm, 100mm ordinary type, 100mm temperature control type (optional Hastelloy temperature control tubes of various lengths) |
| transmittance | 0.01% |
| Data storage | 32G |
| Automatic calibration | Yes. |
| audit trail | Yes. |
| Electronic signature | Yes. |
| Method Library | Yes. |
| multifunctional search | Yes. |
| WIFI printing | Yes. |
| Cloud as a Service | optional |
| MD5 code verification | optional |
| custom formula | optional |
| user management | There is/four-level permission management |
| User disables unlock feature | Yes. |
| Communication interface | USB connection, RS232 connection, VGA, Ethernet |
| Instrument grade | Level 0.01 |
| Miscellaneous Options | Each Capacity 50mm and 200mm long temperature control tube, mouse, keyboard connection, universal printer/wireless network printer |
| Power | 220V±22V，50Hz±1Hz，250W |
| Net Weight | 28kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39137/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
