Specifications
| type | oil free |
| Compression method | piston |
| Exhaust pressure | 8Bar、0.8MPa |
| Displacement | 1500L / min @ 0MPa 、 725L / min @ 0.7MPa |
| Gas storage tank Volume | 330L |
| Noise value | 72dB |
| Dimensions | 1730*530*120mm |
| Weight | 248kg |
| Bore × number of bars | 5 |
| pressure switch | Set start/stop pressure according to customer requirements |
| Accessories | 1. Install oil-water separator; 2. Install automatic drain |
| Power | 220-230V/50/60Hz |
| Packaging Dimensions | 175*55*125cm |
| power | 7.5KW |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39517/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
