Specifications
| Lighting method | 45/0 (45 annular uniform illumination 0 ° reception); conforms to standard CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | Φ48mm |
| Lighting source | Combined LED Light source |
| spectroscopy | Concave grating spectroscopy |
| Sensor | 256 pixel dual array CMOS image sensor |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum half bandwidth | 10nm |
| Reflectance Measurement Range | 0~200% |
| Measurement caliber | Φ8mm |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB,βxy |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE（Hunter） |
| Chroma indicator | WI, YI, TI, homochromatic index MI, colour fastness, colour fastness, force, coverage |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum/data, sample chromatic values, color difference values/plots, pass/fail results, Color bias |
| Measurement time | About 1.5s |
| Spectroscopic reflectance Repeatability | MAV, standard deviation within 0.1% (400~700nm: within 0.2%) |
| Inter-instrument Agreement | ΔE*ab<0.2(MAV) |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| Dimensions | 184*77*105mm |
| Weight | Approx. 600g |
| Battery life | Lithium battery, 5000 cycles in 8 hours |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Interface | USB |
| data storage | 500 master standards, 20,000 samples |
| Operating language | Simplified Chinese, English |
| Operating conditions | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
| Repeatability of chromatic value | MAV,ΔE*ab 0.05COR |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
