IWAVE WF30 16mm particle Colorimeter with liquid and powder multifunctional test piece

SE
With multi-functional test piece, 16mm large diameter, suitable for detecting texture, rough, soft, wet, liquid, slurry, powder, particles and other products, built-in whiteboard automatic correction, repeability accuracy < 0.05, with computer software.
$1827.00/set
PromotionLoading...
Coupon
Certificate
Contact
Details SPEC Con VIDEO CAT OI

IWAVE WF30-16mm + Multifunctional Test Component ColorimeterSPEC

IWAVE WF30-16mm + Multifunctional Test Component ColorimeterDetails

IWAVE WF30-16mm + Multifunctional Test Component ColorimeterPacking list

SKU
NB039532
Lighting method
8°/d
Sensors
photodiode array
Measurement range
L:0~100
Measurement light source
D50,D65,F11(TL84)
Measurement time
0.5s
Measurement caliber
Φ16mm
Repeatability
ΔE*ab<0.05
Operating language
Simplified Chinese, English
Interface
USB2.0(USB-B型)、RS-232(115200bps)
Viewing Angle
CIE 10°
Lighting source
LED blue excitation
Color difference formula
ΔE*ab
data storage
100 master standard data, 200 sample data under each master standard
Power supply Voltage
Lithium battery can be measured 5000 times after being fully charged
display mode
CIELAB、CIELCH
Operating environment
0 ℃ -40 ℃ (32 ° F -104 ° F); Relative Humidity below 85% without condensation
Storage environment
-20 ℃ -50 ℃; Relative Humidity below 85% without condensation
Dimensions
199*68*90mm
Weight
700g
Light-containing method
SCI SCE
Inter-instrument Agreement
ΔE*ab<0.2
Lighting source life
More than 1.60 million measurements in 5 years
Display
TFT true color display 2.8inch @(16:9) resolution: 400x240
Packing size
400*240*340mm
Optional Accessories
Liquid test components, powder test boxes, micro printers
WF30-16mm + Multifunctional Test Component
Colorimeter
With multi-functional test piece, 16mm large diameter, suitable for detecting texture, rough, soft, wet, liquid, slurry, powder, particles and other products, built-in whiteboard automatic correction, repeability accuracy < 0.05, with computer software.
IWAVE WF30 16mm particle Colorimeter with liquid and powder multifunctional test piece Picture

IWave WF30-16mm large-diameter Colorimeter is a WF30 series Colorimeter with a relatively large measuring aperture, which is specially used for color difference measuring instruments for textile fabrics, leather goods, wood furniture, and has a color measurement diameter of 16mm.Due to its large diameter, the WF30-16mm computerized Colorimeter is very suitable for measuring some striped cloth, leather or wood and other products and some large-area color measurement products.WF30-16mm large-diameter Colorimeter is not only professional and practical, but also has the characteristics of high precision and automatic correction, the shape of the fuselage horizontal design, the measurement is stable and no light leakage, which improves the measurement accuracy of the computer Colorimeter.

IWave WF30-16mm computerized Colorimeter 3D animation display

Parameters of IWave WF30-16mm large aperture Colorimeter

Advantages of IWave WF30-16mm Computerized Colorimeter

IWave WF30-16mm computerized Colorimeter application field

IWave WF30-16mm Computerized Colorimeter Authorization Certificate and After-sales Warranty

Front and side view of IWave WF30-16mm computerized Colorimeter

IWave WF30-16mm Computerized Colorimeter Packing List and Interface Details

IWave WF30-16mm computerized Colorimeter application example

Versatile test components

Can be assembled in WF seriesColorimeterThe optical integral cavity (16 mm aperture) and the optical grade quartz container vessel form a multi-functional test accessory, which is suitable for measuring liquids, slurries, powders, and fine granular objects.

Measurement steps

1. Inject the liquid into the quartz cup;

2. Fix the integrating cavity on the Colorimeter;

3. Put the quartz cup into the integral cavity;

4. Cover the lid of the integral cavity;

Waifu liquid powder multi-function test assembly

FAQ
QCan this color difference meter measure the color difference of particles? Larger particles
A You can test the sample of particles, and you need to add a multi-functional test component.
