Specifications
| Measurement caliber | 3 calibers (MAV: Should 8mm/Should 11mm; SAV: Should 4mm/Should 6mm; MINI: 1 * 3mm) |
| Lighting/light receiving system | d/8,SCI |
| Sensors | Dual Array Sensors |
| spectroscopic mode | grating |
| Integrating sphere size | Φ40mm |
| Wavelength Range | 400-700nm |
| Measurement wavelength interval | 10nm |
| Reflectance Measurement Range | 0~200%, resolution: 0.01% |
| Lighting source | Full Band Balanced LED Light source + UV |
| Measurement time | Approximately 1.5 seconds |
| Repeatability | ΔE*ab≤ 0.025 |
| inter-device difference | ΔE*ab≤0.25 |
| Operating language | Simplified Chinese, English |
| Display Accuracy | 0.01 |
| Standard observer | 2°，10° |
| Light source 1 | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12, CWF,U30,U35,DLF,NBF,TL83,TL84 |
| Color space/chroma indicator 1 | Light spectrum reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, color difference (delta E * ab, delta E * cmc, delta E * 94, delta E * 00), |
| Color space/chroma indicator 2 | Whiteness (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, TaubeBergerStensby), Yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness (My, dM) |
| memory | APP Mass storage |
| Port | USB, Bluetooth |
| Battery life | Single charge can be continuously measured 8000 times, 3.7V/3000mAh |
| Camera viewfinder positioning | Yes. |
| Calibration method | Automatic calibration |
| Software support | Android, IOS, WeChat Mini Program, Windows |
| Accuracy | Guaranteed Level 1 Measurement Qualification |
| meet the standard | Compliant with standards CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Display | IPS full color screen 3.5 inches |
| Light source lifetime | 10 years 1 million times |
| Color space/chroma indicator 3 | Tint (ASTM E313-00), color density CMYK (A, T, E, M), isochromatic index Milm, Munsell, hiding power, force (dyestuff strength, tinting strength) |
| Light source 2 | ID50,ID65,LED-B1,LED-B2,LED-B3, LED-B4,LED-B5,LED-BH1,LED-RGB1,LED-V1,LED-V2 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39649/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
